Werksnorm 441-G |
Verstellbare Klemmhebel |
Material: Automatenstahl, Griff aus Zink-Druckguss |
RoHS: konform |
Oberfläche: Stahlteile brüniert, Griff Orange  |
 |  |
| |
 |
technische Details, Abmessungen in [mm]
| d3 | 14 | 14 | 18 | 22 | 25 | 30 |
| d2 | 10 | 10 | 13,5 | 16 | 19 | 23 |
| l2 | 45 | 45 | 62 | 74 | 89 | 108 |
| h | 35 | 35 | 45 | 52 | 63 | 76 |
Stück je Verpackungseinheit
| l1 | d1 | M 5 | M 6 | M 8 | M 10 | M 12 | M 16 |
| 12 | 1 | 1 | ||||
| 16 | 1 | 1 | 1 | |||
| 20 | 1 | 1 | 1 | 1 | ||
| 25 | 1 | 1 | 1 | 1 | ||
| 32 | 1 | 1 | 1 | 1 | 1 | 1 |
| 40 | 1 | 1 | 1 | 1 | 1 | 1 |
| 50 | 1 | 1 | 1 | 1 | ||
| 63 | 1 | 1 | 1 | |||
| 80 | 1 | 1 | ||||
| l1 | d1 | M 5 | M 6 | M 8 | M 10 | M 12 | M 16 |
