DIN 464 |
hohe Rändelschraube |
Material: Stahl Güte 4.8 |
RoHS: konform |
Oberfläche: verzinkt (Chrom 6 frei)   |
 |  |
| |
 |
technische Details, Abmessungen in [mm]
| d1 | M 3 | M 4 | M 5 | M 6 | M 8 |
| d2 | 6 | 8 | 10 | 12 | 16 |
| d3 | 12 | 16 | 20 | 24 | 30 |
| k | 2,5 | 3,5 | 4 | 5 | 6 |
| h | 7,5 | 9,5 | 11,5 | 15 | 18 |
Stück je Verpackungseinheit
| l | d1 | M 3 | M 4 | M 5 | M 6 | M 8 |
| 6 | 50 | 50 | |||
| 8 | 50 | 50 | 50 | ||
| 10 | 50 | 50 | 50 | 25 | |
| 12 | 50 | 50 | 25 | 25 | |
| 16 | 50 | 50 | 50 | 25 | 25 |
| 20 | 50 | 50 | 25 | 25 | |
| 25 | 25 | 25 | |||
| 30 | 25 | ||||
| 35 | 25 | ||||
| 40 | |||||
| l | d1 | M 3 | M 4 | M 5 | M 6 | M 8 |
