Werksnorm 2275
Kugeldruckschrauben
Material: Automatenstahl, abgeflachte Kugel aus Stahl
RoHS: konform
Oberfläche: schwarz
Werksnorm 2275 KugeldruckschraubenWerksnorm 2275 Kugeldruckschrauben
Werksnorm 2275 Kugeldruckschrauben
Werksnorm 2275 Kugeldruckschrauben

technische Details, Abmessungen in [mm]
K d2 SW
2,5 1,8 2
2,5 1,8 2
2,5 1,8 2
2,5 1,8 2
3 2,2 2,5
3 2,2 2,5
3 2,2 2,5
3 2,2 2,5
3 2,2 2,5
3 2,2 2,5
4 3,2 3
4 3,2 3
4 3,2 3
4 3,2 3
4 3,2 3
5,5 4,5 4
5,5 4,5 4
5,5 4,5 4
5,5 4,5 4
5,5 4,5 4
5,5 4,5 4
7 6 5
7 6 5
7 6 5
7 6 5
7 6 5
7 6 5
d1 x l2
M 4 x 5,6 10
M 4 x 9,6 10
M 4 x 11,6 10
M 4 x 15,6 10
M 5 x 7,5 10
M 5 x 9,5 10
M 5 x 11,5 10
M 5 x 15,5 10
M 5 x 19,5 10
M 5 x 24,5 10
M 6 x 10 10
M 6 x 12 10
M 6 x 16 10
M 6 x 20 10
M 6 x 25 10
M 8 x 10 10
M 8 x 12 10
M 8 x 16 10
M 8 x 20 10
M 8 x 25 10
M 8 x 30 10
M 10 x 12 10
M 10 x 16 10
M 10 x 20 10
M 10 x 25 10
M 10 x 30 10
M 10 x 35 10
